Best Price of Portable IGBT induction Bolt heating Machine With Indstrial chiller on turbines (hydraulic, steam, gas)
Induction Heating Bolt machine :
Induction bolt heating involves heating drilled stud bolts to obtain elongation. Thus, it only takes a few minutes to heat them evenly and safely. This process is 2 to 3 times faster than conventional heating means such as heating rods
A proven method
In 2018we launched our first machines and our first interventions. Since then, we have traveled across Europe and even the world: Japan, China, USA, Mexico, Turkey, UK, France…
Our main induction tightening operations are carried out on turbines (hydraulic, steam, gas) and compressors of all sizes.
The advantages of our induction bolt heating service
Easy to set up and use: all you need is a 380 -480 volts 32A outlet
Light & compact design,
Can connect industrail chiller Cooling system with machine
Timer integrated to control heating time
User-friendly, easy to operate with automatic or manual power regulation
3-80meters length of coaxial cable to access both sides of the turbine
No exceeding of the Curie point (no material transformation)
No burning risk as inductor remains cold
All sizes inductors manufacturing, in 72 hours on demand
Only heat the center of the bolt, for accurate tightening and to minimize heat dispersion
Quick heating time
The techincal parameters of induction heating bolt machine :
| Type | DSP-80KW |
| Rated Output Power | 80KW |
| Rated Output Frequency | 10-40KHZ |
| Can expand frquency | 1-100khz |
| Overload Heating time | 45%/10min |
| Power Adjust Arrange | 1.5-100% |
| Coaxial Flexible cable length | 5M,6M...10M,20M,30M,40M,50M |
| Input Voltage | 360-420v 50-60hz |
| Max power | 80kw |
| Protection Level | IP54 |
| Environment Temperature | +5c--+50C |
| Cooling water flow | 31L/MIN |
| Cooling water Pressure | 4-8Bar |
| Weight | About 180kg |
Induction heating machine applications:
|
|
Best Price of Portable IGBT induction Bolt heating Machine With Indstrial chiller on turbines (hydraulic, steam, gas) Images
|
